型號 |
TYPE |
MSG630R-R |
MSG1000R-R |
MSG1300R-R |
|
加工寬度 |
Working Width |
40--630mm |
40--1000mm |
40--1300mm |
|
加工厚度 |
Working Thickness |
2--100mm |
2--100mm |
2--100mm |
|
加工板材長度 |
Working Length |
≥270mm |
≥270mm |
≥310mm |
|
送料速度 |
Feed Speed |
0--18m/min變頻調(diào)速 |
0--18m/min變頻調(diào)速 |
0--18m/min變頻調(diào)速 |
|
砂帶尺寸 |
Size of Abrasive Belt |
650*1900mm |
1020*2000mm |
1320*2200mm |
|
電機總功率 |
Total Motor Power |
10.2KW |
17.2KW |
26KW |
|
工作氣壓 |
Working Air Perssure |
≥0.6Mpa |
≥0.6Mpa |
≥0.6Mpa |
|
工作電壓 |
Working Voltage |
380V 50HZ |
380V 50HZ |
380V 50HZ |
|
吸塵風速 |
Speed Of Suckeed Air |
8200m3/h |
8200m3/h |
8200m3/h |
